Xpres Cargo Trailers

What you’ll get:

  • 2’ V-Nose, Flat Roof Design
  • 31” Barlock Style Side Door (Optional 5w)
  • All LED Exterior/Interior Lights
  • Radial Tires on Modular Style Wheels
  • 73” Rear Opening Standard (6w and Up)
Request a Quote Locate a Dealer

Xpres Enclosed Cargo Trailers are the latest edition to the Mirage Trailers line. Triple-sealed roofs ensure leak-proof reliability and durability. The flat-top roof and v-nose design provide tons of extra interior volume and clearance at the rear entry. You get a 73” rear opening on 6, 7, and 8.5 wide models standard. Tube steel roof bows, wall studs, radial tires, LED lights, and .030 exterior skin are also standard. Add the popular Xtra Package for even more utility and functionality. On 7 wide and 8.5 wide models, add the Side by Side package for your UTVs. The Car Carrier package is available on 8.5 wides. Also, ask your dealer about the Black Accent Package.

SINGLE AXLE

Frame
Coupler2" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue3 x 2" Tube (7w - 4 x 2")
Frame3 x 2" Tube
Crossmembers24" o/c Z Form
Floor3/4" Engineered Wood
Wall Studs24" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V NoseYes
Rear DoorsRear Ramp or Swing Door(s)
Entry Door32" Prehung (n/a on 5w)
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo ControlOptional
Roof
RoofGalvanized
Roof Bows24" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
VentsOptional
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Idler
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Radius
Fender BoxesN/A
Spare TireOptional
Spare MountOptional
Electrical
Wiring4-Way
Interior LightsLED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

TANDEM AXLE

Frame
Coupler2 5/16" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue4 x 2" Tube
Frame3 x 2" Tube
Crossmembers24" o/c Z Form
Floor3/4" Engineered Wood
Wall Studs16" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V NoseYes
Rear DoorsRear Ramp or Rear Double Doors
Entry Door32" Prehung
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo ControlOptional
Roof
RoofGalvanized
Roof Bows24" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
VentsOptional
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Brake
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Teardrop
Fender BoxesN/A
Spare TireOptional
Spare MountOptional
Electrical
Wiring7-Way w/ Jct. Box, Breakaway
Interior LightsLED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

TANDEM AXLE

Frame
Coupler2 5/16" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue4 x 2" Tube
Frame3 x 2" Tube
Crossmembers24" o/c Z Form
Floor3/4" Engineered Wood
Wall Studs16" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V Nosen/a
Rear DoorsRear Ramp or Rear Double Doors
Entry Door32" Prehung
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo ControlOptional
Roof
RoofGalvanized
Roof Bows24" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
VentsOptional
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Brake
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Teardrop
Fender BoxesN/A
Spare TireOptional
Spare MountOptional
Electrical
Wiring7-Way w/ Jct. Box, Breakaway
Interior LightsLED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

8.5 WIDE

Frame
Coupler2 5/16" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue5 x 2" Tube (14K GVWR - 6 x 2")
Frame6" I-Beam (14K GVWR - 8" I-Beam )
Crossmembers16" o/c Z Form
Floor3/4" Engineered Wood
Wall Studs16" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V NoseYes
Rear DoorsRear Ramp or Rear Double Doors
Entry Door32" Prehung
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo ControlOptional
Roof
RoofGalvanized
Roof Bows16" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
VentsOptional
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Brake
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Teardrop
Fender BoxesDepends on Axle
Spare TireOptional
Spare MountOptional
Electrical
Wiring7-Way w/ Jct. Box, Breakaway
Interior LightsLED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

8.5 WIDE

Frame
Coupler2 5/16" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue6 x 2" Tube
Frame8" I-Beam
Crossmembers16" o/c Z Form
Floor3/4" Engineered Wood w/ Beavertail
Wall Studs16" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V NoseYes
Rear DoorsRear Ramp
Entry Door32" Prehung
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo ControlOptional
Roof
RoofGalvanized
Roof Bows16" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
Vents(1) Roof
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Brake
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Teardrop
Fender BoxesDepends on Axle
Spare TireOptional
Spare MountInterior
Electrical
Wiring7-Way w/ Jct. Box, Breakaway
Interior Lights(2) LED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

TANDEM AXLE

Frame
Coupler2 5/16" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue4 x 2" Tube
Frame3 x 2" Tube
Crossmembers24" o/c Z Form
Floor3/4" Engineered Wood
Wall Studs16" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V NoseYes
Rear DoorsRear Ramp
Entry Door32" Prehung (Driver's Side)
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo Control(2) Recessed D-Rings, (4) Rope Ties
Roof
RoofGalvanized
Roof Bows24" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
Vents(1) Roof, (2) Scoop
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Brake
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Teardrop
Fender Boxesn/a
Spare TireOptional
Spare MountInterior
Electrical
Wiring7-Way w/ Jct. Box, Breakaway
Interior Lights(2) LED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

TANDEM AXLE

Frame
Coupler2 5/16" A-Frame
Jack2K Top Wind w/ Adj Jack Foot
Tongue4 x 2" Tube
Frame3 x 2" Tube
Crossmembers24" o/c Z Form
Floor3/4" Engineered Wood
Wall Studs16" o/c Tube
Side Walls3/8" Engineered Wood w/ H-Molding
V NoseYes
Rear DoorsRear Ramp
Entry Door32" Prehung (Driver's Side)
Front RampN/A
Fuel DoorN/A
Interior
Interior TrimOptional
Ceiling LinerOptional
Cargo Control(2) Recessed D-Rings, (4) Rope Ties
Roof
RoofGalvanized
Roof Bows24" o/c Tube
Roof Capn/a
Roof CoveExtruded Aluminum Top Rail
Exterior
Stoneguard24" ATP
Vents(1) Roof, (2) Scoop
Exterior TrimOptional
Ramp Hinge CoverOptional
Wheels & Suspension
AxlesMulti-Leaf Spring Brake
Wheels and TiresRadial Tires on Black Mod Wheels
FendersATP Teardrop
Fender BoxesDepends on Axle
Spare TireOptional
Spare MountInterior
Electrical
Wiring7-Way w/ Jct. Box, Breakaway
Interior Lights(2) LED Dome w/ Wall Switch
Exterior LightsAll LED
Load LightsOptional

8.5x24 Tandem Axle 14K

DESCRIPTION8.5x24 Tandem Axle 14K
SIZE8.5x24
GVWR14000
OPEN W91
OPEN H73
DRY WGT3510
PAYLOAD10490
HITCH WGT351
TOT W102
TOT H99
TOT L341
INT H77 1/2
STUD H84 3/4
INT L310
INT W96
HITCH WGT351
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH288

8.5x22 Tandem Axle 14K

DESCRIPTION8.5x22 Tandem Axle 14K
SIZE8.5x22
GVWR14000
OPEN W91
OPEN H73
DRY WGT3225
PAYLOAD10775
HITCH WGT322 1/2
TOT W102
TOT H99
TOT L317
INT H77 1/2
STUD H84 3/4
INT L286
INT W96
HITCH WGT322 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH264

8.5x20 Tandem Axle 14K

DESCRIPTION8.5x20 Tandem Axle 14K
SIZE8.5x20
GVWR14000
OPEN W91
OPEN H73
DRY WGT2985
PAYLOAD11015
HITCH WGT298 1/2
TOT W102
TOT H99
TOT L293
INT H77 1/2
STUD H84 3/4
INT L262
INT W96
HITCH WGT298 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH240

8.5x18 Tandem Axle 14K

DESCRIPTION8.5x18 Tandem Axle 14K
SIZE8.5x18
GVWR14000
OPEN W91
OPEN H73
DRY WGT2565
PAYLOAD11435
HITCH WGT256 1/2
TOT W102
TOT H99
TOT L269
INT H77 1/2
STUD H84 3/4
INT L238
INT W96
HITCH WGT256 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH216

8.5x16 Tandem Axle 14K

DESCRIPTION8.5x16 Tandem Axle 14K
SIZE8.5x16
GVWR14000
OPEN W91
OPEN H73
DRY WGT2415
PAYLOAD11585
HITCH WGT241 1/2
TOT W102
TOT H99
TOT L245
INT H77 1/2
STUD H84 3/4
INT L214
INT W96
HITCH WGT241 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH192

8.5x24 Tandem Axle 10K

DESCRIPTION8.5x24 Tandem Axle 10K
SIZE8.5x24
GVWR9990
OPEN W91
OPEN H73
DRY WGT3510
PAYLOAD6480
HITCH WGT351
TOT W102
TOT H99
TOT L341
INT H77 1/2
STUD H84 3/4
INT L310
INT W96
HITCH WGT351
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH288

8.5x22 Tandem Axle 10K

DESCRIPTION8.5x22 Tandem Axle 10K
SIZE8.5x22
GVWR9990
OPEN W91
OPEN H73
DRY WGT3225
PAYLOAD6765
HITCH WGT322 1/2
TOT W102
TOT H99
TOT L317
INT H77 1/2
STUD H84 3/4
INT L286
INT W96
HITCH WGT322 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH264

8.5x20 Tandem Axle 10K

DESCRIPTION8.5x20 Tandem Axle 10K
SIZE8.5x20
GVWR9990
OPEN W91
OPEN H73
DRY WGT2985
PAYLOAD7005
HITCH WGT298 1/2
TOT W102
TOT H99
TOT L293
INT H77 1/2
STUD H84 3/4
INT L262
INT W96
HITCH WGT298 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH240

8.5x18 Tandem Axle 10K

DESCRIPTION8.5x18 Tandem Axle 10K
SIZE8.5x18
GVWR9990
OPEN W91
OPEN H73
DRY WGT2565
PAYLOAD7425
HITCH WGT256 1/2
TOT W102
TOT H99
TOT L269
INT H77 1/2
STUD H84 3/4
INT L238
INT W96
HITCH WGT256 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH216

8.5x16 Tandem Axle 10K

DESCRIPTION8.5x16 Tandem Axle 10K
SIZE8.5x16
GVWR9990
OPEN W91
OPEN H73
DRY WGT2415
PAYLOAD7575
HITCH WGT241 1/2
TOT W102
TOT H99
TOT L245
INT H77 1/2
STUD H84 3/4
INT L214
INT W96
HITCH WGT241 1/2
HITCH H22
FLOOR H22
BOX WIDTH100
BOX LENGTH192

8.5x24 Tandem Axle 7K

DESCRIPTION8.5x24 Tandem Axle 7K
SIZE8.5x24
GVWR7000
OPEN W91
OPEN H73
DRY WGT3475
PAYLOAD3525
HITCH WGT347 1/2
TOT W102
TOT H99
TOT L341
INT H77 1/2
STUD H84 3/4
INT L310
INT W96
HITCH WGT347 1/2
HITCH H20
FLOOR H22
BOX WIDTH100
BOX LENGTH288

8.5x22 Tandem Axle 7K

DESCRIPTION8.5x22 Tandem Axle 7K
SIZE8.5x22
GVWR7000
OPEN W91
OPEN H73
DRY WGT3190
PAYLOAD3810
HITCH WGT319
TOT W102
TOT H99
TOT L317
INT H77 1/2
STUD H84 3/4
INT L286
INT W96
HITCH WGT319
HITCH H20
FLOOR H22
BOX WIDTH100
BOX LENGTH264

8.5x20 Tandem Axle 7K

DESCRIPTION8.5x20 Tandem Axle 7K
SIZE8.5x20
GVWR7000
OPEN W91
OPEN H73
DRY WGT2950
PAYLOAD4050
HITCH WGT295
TOT W102
TOT H99
TOT L293
INT H77 1/2
STUD H84 3/4
INT L262
INT W96
HITCH WGT295
HITCH H20
FLOOR H22
BOX WIDTH100
BOX LENGTH240

8.5x18 Tandem Axle 7K

DESCRIPTION8.5x18 Tandem Axle 7K
SIZE8.5x18
GVWR7000
OPEN W91
OPEN H73
DRY WGT2530
PAYLOAD4470
HITCH WGT253
TOT W102
TOT H99
TOT L269
INT H77 1/2
STUD H84 3/4
INT L238
INT W96
HITCH WGT253
HITCH H20
FLOOR H22
BOX WIDTH100
BOX LENGTH216

8.5x16 Tandem Axle 7K

DESCRIPTION8.5x16 Tandem Axle 7K
SIZE8.5x16
GVWR7000
OPEN W91
OPEN H73
DRY WGT2380
PAYLOAD4620
HITCH WGT238
TOT W102
TOT H99
TOT L245
INT H77 1/2
STUD H84 3/4
INT L214
INT W96
HITCH WGT238
HITCH H20
FLOOR H22
BOX WIDTH100
BOX LENGTH192

8.5x14 Tandem Axle 7K

DESCRIPTION8.5x14 Tandem Axle 7K
SIZE8.5x14
GVWR7000
OPEN W91
OPEN H73
DRY WGT2050
PAYLOAD4950
HITCH WGT205
TOT W102
TOT H99
TOT L221
INT H77 1/2
STUD H84 3/4
INT L190
INT W96
HITCH WGT205
HITCH H20
FLOOR H22
BOX WIDTH100
BOX LENGTH168

7x18 Tandem Axle Round Front 7K

DESCRIPTION7x18 Tandem Axle Round Front 7K
SIZE7x18
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT2320
PAYLOAD4680
HITCH WGT232
TOT W102
TOT H98
TOT L266
INT H77
STUD H78 3/4
INT L222
INT W80
HITCH WGT232
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH216

7x16 Tandem Axle Round Front 7K

DESCRIPTION7x16 Tandem Axle Round Front 7K
SIZE7x16
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT2200
PAYLOAD4800
HITCH WGT220
TOT W102
TOT H98
TOT L242
INT H77
STUD H78 3/4
INT L198
INT W80
HITCH WGT220
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH192

7x14 Tandem Axle Round Front 7K

DESCRIPTION7x14 Tandem Axle Round Front 7K
SIZE7x14
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT2080
PAYLOAD4920
HITCH WGT208
TOT W102
TOT H98
TOT L218
INT H77
STUD H78 3/4
INT L174
INT W80
HITCH WGT208
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH168

7x12 Tandem Axle Round Front 7K

DESCRIPTION7x12 Tandem Axle Round Front 7K
SIZE7x12
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT1960
PAYLOAD5040
HITCH WGT196
TOT W102
TOT H98
TOT L194
INT H77
STUD H78 3/4
INT L150
INT W80
HITCH WGT196
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH144

6x14 Tandem Axle Round Front 7K

DESCRIPTION6x14 Tandem Axle Round Front 7K
SIZE6x14
GVWR7000
OPEN W63
OPEN H72 1/2
DRY WGT1640
PAYLOAD5360
HITCH WGT164
TOT W90
TOT H98
TOT L212
INT H77
STUD H78 3/4
INT L174
INT W68
HITCH WGT164
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH168

6x12 Tandem Axle Round Front 7K

DESCRIPTION6x12 Tandem Axle Round Front 7K
SIZE6x12
GVWR7000
OPEN W63
OPEN H72 1/2
DRY WGT1540
PAYLOAD5460
HITCH WGT154
TOT W90
TOT H98
TOT L188
INT H77
STUD H78 3/4
INT L150
INT W68
HITCH WGT154
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH144

6x10 Tandem Axle Round Front 7K

DESCRIPTION6x10 Tandem Axle Round Front 7K
SIZE6x10
GVWR7000
OPEN W63
OPEN H72 1/2
DRY WGT1440
PAYLOAD5560
HITCH WGT144
TOT W90
TOT H98
TOT L164
INT H77
STUD H78 3/4
INT L126
INT W68
HITCH WGT144
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH120

7x18 Tandem Axle 7K

DESCRIPTION7x18 Tandem Axle 7K
SIZE7x18
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT2320
PAYLOAD4680
HITCH WGT232
TOT W102
TOT H98
TOT L266
INT H77
STUD H78 3/4
INT L238
INT W80
HITCH WGT232
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH216

7x16 Tandem Axle 7K

DESCRIPTION7x16 Tandem Axle 7K
SIZE7x16
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT2200
PAYLOAD4800
HITCH WGT220
TOT W102
TOT H98
TOT L242
INT H77
STUD H78 3/4
INT L214
INT W80
HITCH WGT220
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH192

7x14 Tandem Axle 7K

DESCRIPTION7x14 Tandem Axle 7K
SIZE7x14
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT2080
PAYLOAD4920
HITCH WGT208
TOT W102
TOT H98
TOT L218
INT H77
STUD H78 3/4
INT L190
INT W80
HITCH WGT208
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH168

7x12 Tandem Axle 7K

DESCRIPTION7x12 Tandem Axle 7K
SIZE7x12
GVWR7000
OPEN W75
OPEN H72 1/2
DRY WGT1960
PAYLOAD5040
HITCH WGT196
TOT W102
TOT H98
TOT L194
INT H77
STUD H78 3/4
INT L166
INT W80
HITCH WGT196
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH144

6x14 Tandem Axle 7K

DESCRIPTION6x14 Tandem Axle 7K
SIZE6x14
GVWR7000
OPEN W63
OPEN H72 1/2
DRY WGT1640
PAYLOAD5360
HITCH WGT164
TOT W90
TOT H98
TOT L212
INT H77
STUD H78 3/4
INT L190
INT W68
HITCH WGT164
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH168

6x12 Tandem Axle 7K

DESCRIPTION6x12 Tandem Axle 7K
SIZE6x12
GVWR7000
OPEN W63
OPEN H72 1/2
DRY WGT1540
PAYLOAD5460
HITCH WGT154
TOT W90
TOT H98
TOT L188
INT H77
STUD H78 3/4
INT L166
INT W68
HITCH WGT154
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH144

6x10 Tandem Axle 7K

DESCRIPTION6x10 Tandem Axle 7K
SIZE6x10
GVWR7000
OPEN W63
OPEN H72 1/2
DRY WGT1440
PAYLOAD5560
HITCH WGT144
TOT W90
TOT H98
TOT L164
INT H77
STUD H78 3/4
INT L142
INT W68
HITCH WGT144
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH120

7x12 Single Axle Round Front 3.5K

DESCRIPTION7x12 Single Axle Round Front 3.5K
SIZE7x12
GVWR3500
OPEN W75
OPEN H72 1/2
DRY WGT1590
PAYLOAD1910
HITCH WGT159
TOT W102
TOT H98
TOT L194
INT H77
STUD H78 3/4
INT L150
INT W80
HITCH WGT159
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH144

6x14 Single Axle Round Front 3.5K

DESCRIPTION6x14 Single Axle Round Front 3.5K
SIZE6x14
GVWR3500
OPEN W63
OPEN H72 1/2
DRY WGT1400
PAYLOAD2100
HITCH WGT140
TOT W90
TOT H98
TOT L212
INT H77
STUD H78 3/4
INT L174
INT W68
HITCH WGT140
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH168

6x12 Single Axle Round Front 3.5K

DESCRIPTION6x12 Single Axle Round Front 3.5K
SIZE6x12
GVWR3500
OPEN W63
OPEN H72 1/2
DRY WGT1300
PAYLOAD2200
HITCH WGT130
TOT W90
TOT H98
TOT L188
INT H77
STUD H78 3/4
INT L150
INT W68
HITCH WGT130
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH144

6x10 Single Axle Round Front 3.5K

DESCRIPTION6x10 Single Axle Round Front 3.5K
SIZE6x10
GVWR3500
OPEN W63
OPEN H72 1/2
DRY WGT1200
PAYLOAD2300
HITCH WGT120
TOT W90
TOT H98
TOT L164
INT H77
STUD H78 3/4
INT L126
INT W68
HITCH WGT120
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH120

5x10 Single Axle Round Front 3.5K

DESCRIPTION5x10 Single Axle Round Front 3.5K
SIZE5x10
GVWR3500
OPEN W51
OPEN H58 1/2
DRY WGT1040
PAYLOAD2460
HITCH WGT104
TOT W78
TOT H80
TOT L164
INT H63
STUD H64 3/4
INT L126
INT W56
HITCH WGT104
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH120

5x8 Single Axle Round Front 3.5K

DESCRIPTION5x8 Single Axle Round Front 3.5K
SIZE5x8
GVWR3500
OPEN W51
OPEN H58 1/2
DRY WGT940
PAYLOAD2560
HITCH WGT94
TOT W78
TOT H80
TOT L140
INT H63
STUD H64 3/4
INT L102
INT W56
HITCH WGT94
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH96

7x12 Single Axle 3.5K

DESCRIPTION7x12 Single Axle 3.5K
SIZE7x12
GVWR3500
OPEN W75
OPEN H72 1/2
DRY WGT1590
PAYLOAD1910
HITCH WGT159
TOT W102
TOT H98
TOT L194
INT H77
STUD H78 3/4
INT L166
INT W80
HITCH WGT159
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH144

6x14 Single Axle 3.5K

DESCRIPTION6x14 Single Axle 3.5K
SIZE6x14
GVWR3500
OPEN W63
OPEN H72 1/2
DRY WGT1400
PAYLOAD2100
HITCH WGT140
TOT W90
TOT H98
TOT L212
INT H77
STUD H78 3/4
INT L190
INT W68
HITCH WGT140
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH168

6x12 Single Axle 3.5K

DESCRIPTION6x12 Single Axle 3.5K
SIZE6x12
GVWR3500
OPEN W63
OPEN H72 1/2
DRY WGT1300
PAYLOAD2200
HITCH WGT130
TOT W90
TOT H98
TOT L188
INT H77
STUD H78 3/4
INT L166
INT W68
HITCH WGT130
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH144

6x10 Single Axle 3.5K

DESCRIPTION6x10 Single Axle 3.5K
SIZE6x10
GVWR3500
OPEN W63
OPEN H72 1/2
DRY WGT1200
PAYLOAD2300
HITCH WGT120
TOT W90
TOT H98
TOT L164
INT H77
STUD H78 3/4
INT L142
INT W68
HITCH WGT120
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH120

5x10 Single Axle 3.5K

DESCRIPTION5x10 Single Axle 3.5K
SIZE5x10
GVWR3500
OPEN W51
OPEN H58 1/2
DRY WGT1040
PAYLOAD2460
HITCH WGT104
TOT W78
TOT H80
TOT L164
INT H63
STUD H64 3/4
INT L142
INT W56
HITCH WGT104
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH120

5x8 Single Axle 3.5K

DESCRIPTION5x8 Single Axle 3.5K
SIZE5x8
GVWR3500
OPEN W51
OPEN H58 1/2
DRY WGT940
PAYLOAD2560
HITCH WGT94
TOT W78
TOT H80
TOT L140
INT H63
STUD H64 3/4
INT L118
INT W56
HITCH WGT94
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH96

7x12 Single Axle Round Front 3K

DESCRIPTION7x12 Single Axle Round Front 3K
SIZE7x12
GVWR3500
OPEN W75
OPEN H72 1/2
DRY WGT1590
PAYLOAD1910
HITCH WGT159
TOT W102
TOT H98
TOT L194
INT H77
STUD H78 3/4
INT L150
INT W80
HITCH WGT159
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH144

6x14 Single Axle Round Front 3K

DESCRIPTION6x14 Single Axle Round Front 3K
SIZE6x14
GVWR2990
OPEN W63
OPEN H72 1/2
DRY WGT1400
PAYLOAD1590
HITCH WGT140
TOT W90
TOT H98
TOT L212
INT H77
STUD H78 3/4
INT L174
INT W68
HITCH WGT140
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH168

6x12 Single Axle Round Front 3K

DESCRIPTION6x12 Single Axle Round Front 3K
SIZE6x12
GVWR2990
OPEN W63
OPEN H72 1/2
DRY WGT1300
PAYLOAD1690
HITCH WGT130
TOT W90
TOT H98
TOT L188
INT H77
STUD H78 3/4
INT L150
INT W68
HITCH WGT130
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH144

6x10 Single Axle Round Front 3K

DESCRIPTION6x10 Single Axle Round Front 3K
SIZE6x10
GVWR2990
OPEN W63
OPEN H72 1/2
DRY WGT1200
PAYLOAD1790
HITCH WGT120
TOT W90
TOT H98
TOT L164
INT H77
STUD H78 3/4
INT L126
INT W68
HITCH WGT120
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH120

5x10 Single Axle Round Front 3K

DESCRIPTION5x10 Single Axle Round Front 3K
SIZE5x10
GVWR2990
OPEN W51
OPEN H58 1/2
DRY WGT1040
PAYLOAD1950
HITCH WGT104
TOT W78
TOT H80
TOT L164
INT H63
STUD H64 3/4
INT L126
INT W56
HITCH WGT104
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH120

5x8 Single Axle Round Front 3K

DESCRIPTION5x8 Single Axle Round Front 3K
SIZE5x8
GVWR2990
OPEN W51
OPEN H58 1/2
DRY WGT940
PAYLOAD2050
HITCH WGT94
TOT W78
TOT H80
TOT L140
INT H63
STUD H64 3/4
INT L102
INT W56
HITCH WGT94
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH96

7x12 Single Axle 3K

DESCRIPTION7x12 Single Axle 3K
SIZE7x12
GVWR2990
OPEN W75
OPEN H72 1/2
DRY WGT1590
PAYLOAD1400
HITCH WGT159
TOT W102
TOT H98
TOT L194
INT H77
STUD H78 3/4
INT L166
INT W80
HITCH WGT159
HITCH H18
FLOOR H20
BOX WIDTH84
BOX LENGTH144

6x14 Single Axle 3K

DESCRIPTION6x14 Single Axle 3K
SIZE6x14
GVWR2990
OPEN W63
OPEN H72 1/2
DRY WGT1400
PAYLOAD1590
HITCH WGT140
TOT W90
TOT H98
TOT L212
INT H77
STUD H78 3/4
INT L190
INT W68
HITCH WGT140
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH168

6x12 Single Axle 3K

DESCRIPTION6x12 Single Axle 3K
SIZE6x12
GVWR2990
OPEN W63
OPEN H72 1/2
DRY WGT1300
PAYLOAD1690
HITCH WGT130
TOT W90
TOT H98
TOT L188
INT H77
STUD H78 3/4
INT L166
INT W68
HITCH WGT130
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH144

6x10 Single Axle 3K

DESCRIPTION6x10 Single Axle 3K
SIZE6x10
GVWR2990
OPEN W63
OPEN H72 1/2
DRY WGT1200
PAYLOAD1790
HITCH WGT120
TOT W90
TOT H98
TOT L164
INT H77
STUD H78 3/4
INT L142
INT W68
HITCH WGT120
HITCH H18
FLOOR H20
BOX WIDTH72
BOX LENGTH120

5x10 Single Axle 3K

DESCRIPTION5x10 Single Axle 3K
SIZE5x10
GVWR2990
OPEN W51
OPEN H58 1/2
DRY WGT1040
PAYLOAD1950
HITCH WGT104
TOT W78
TOT H80
TOT L164
INT H63
STUD H64 3/4
INT L142
INT W56
HITCH WGT104
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH120

5x8 Single Axle 3K

DESCRIPTION5x8 Single Axle 3K
SIZE5x8
GVWR2990
OPEN W51
OPEN H58 1/2
DRY WGT940
PAYLOAD2050
HITCH WGT94
TOT W78
TOT H80
TOT L140
INT H63
STUD H64 3/4
INT L118
INT W56
HITCH WGT94
HITCH H18
FLOOR H20
BOX WIDTH60
BOX LENGTH96
Penske Yellow
Victory Red
Champagne Beige
Forest Green
Schneider Orange
Charcoal Metallic
Silver
Indigo Blue
Dove Grey
Brandy Wine
White
Black

*Disclaimer: Colors shown are approximate. Actual colors will vary slightly from what is shown.

Warranty View, Download, Claim, or Register
Request a Quote
If you have any questions about Mirage Trailers, fill out the information below, and we'll be in touch as soon as we can.
  • This field is for validation purposes and should be left unchanged.
